Brand Haier
-
Model 13 HFAB
-
Capacity wise: 1-Ton
-
Category wise: DC Inverter
-
Color: Grey
-
Cooling Capacity BTU: 14000
-
Running Current Cooling (A): 1.6 ~ 6.5
-
Power input Cooling (KW): 0.36 ~ 1.39
-
Heating Capacity BTU: 13500
-
Running Current Heating (A): 1.6 ~ 5.7
-
Power Input Heating (KW): 0.36 ~ 1.25
-
Other Parameters
-
Input Power Supply (Ph, VAC, Hz): 1PH,230V ̴, 50Hz
-
Air Flow Volume (m3/h): 750
-
Refrigerant Type: R-32
-
Refrigerant Amount (G): 750
-
Indoor & Outdoor Parameters
-
Indoor Net Dimension (L*W*H) mm³: 850*295*210
-
Indoor Packing Net Dimension (L*W*H) mm³): 952*389*283
-
Indoor Net Weight (kg): 11.5
-
Indoor Gross Weight (kg): 14.1
-
Outdoor Net Dimension (L*W*H) mm³: 800*345*560
-
Outdoor Packing Net Dimension (L*W*H) mm³: 908*405*625
-
Outdoor Net Weight (kg): 27
-
Outdoor Gross Weight (kg): 30.5
-
Features
-
Cooling: Yes
-
Heating: Yes
-
Dry: Yes
-
Vertical Flapper Auto Swing: Yes
-
Horizontal Louvers Auto Swing Yes
-
Air-Purification With UV Technology: No
-
WiFi: Yes
-
Self-Clean: Yes
-
Anti-Corrosion: Yes
-
Turbo Function: Yes
-
ECO Mode: Yes
-
Accessories
-
Installation Kit (Liquid side) Material*Length*Dia*Thickness (mm): Copper * 2920*6*0.65 (6mm)
-
Installation Kit (Gas side) Material*Length*Dia*Thickness (mm): Copper * 2920*12*0.65 (12mm)
-
Power Cable (Core*mm²): 3*2.5
-
Communication Cable b/w Indoor & Outdoor (Core*mm²): 4*2.5
-
Warranty
-
Compressor 10 Years
-
Evaporator 03 Years
-
PCB 04 Years
-
Parts 1 Year
