Philips 162B9T 15.6 Inch 10 point Touch LCD Monitor with LED Backlights with Smooth Touch, 1366 X 768 HD, USB 3.1, Display Port, HDMI Port, Smart Stand, Smart Contrast, Easy Read Mode, Low Blue Mode

Connectivity

Signal Input

• VGA (Analogue)
• DVI-D (digital, HDCP)
• DisplayPort 1.2
• HDMI 1.4

USB

• USB 3.1 x 2 (1 w/fast charging)

Sync Input

• Separate Sync
• Sync on Green

Audio (In/Out)

• PC audio-in
• Headphone out

HDCP

• HDCP: HDCP 1.4 (HDMI/DP/DVI)

Picture/Display

Panel Size 15.6 inch/39.6 cm

Aspect ratio 16:9

LCD panel type TFT-LCD (TN)

Backlight type - W-LED system

Pixel pitch 0.252 x 0.252 mm

Optimum resolution 1366 x 768 @ 60 Hz

Brightness 220  cd/m²

Display colours 262 K

Colour gamut (typical) NTSC 86%*, sRGB 100%*

Contrast ratio (typical) 500:1

SmartContrast 20,000,000:1

Response time (typical) 4 ms (Grey to Grey)*

Viewing angle 90º (H) / 60º (V) @ C/R > 10

Picture enhancement SmartImage

Effective viewing area 344.2 (H) x 193.5 (V)

Scanning Frequency 30–60 kHz (H)/50–75 Hz (V)

sRGB Yes

Pixel Density 100 PPI

LowBlue Mode Yes

EasyRead Yes

Touch

Ingress protection IP65 - front only

Operating system Windows 10 / 8.1 / 8 / 7; Android 7.1 / 7.0 / 6.0 / 5.0 / 4.4; certain Linux versions*

Sealability Touchscreen sealed to bezel; Touchscreen sealed to LCD

Touch active area 344.2 mm (H) x 193.5 mm (V)

Touch glass hardness 7 H

Touch interface USB

Touch method Stylus, Finger, Glove*

Touch points 10 points

Touch technology Projected capacitive

Palm rejection area >= 25 x 25 mm

Touch glass coating Glare

Convenience

Built-in Speakers 2 W x 2

Plug and Play Compatibility

• DDC/CI
• sRGB
• Windows 10 / 8.1 / 8 / 7

User convenience

• SmartImage
• Input
• Brightness
• Menu
• Power On/Off

OSD Languages

• Brazil Portuguese
• Czech
• Dutch
• English
• Finnish
• French
• German
• Greek
• Hungarian
• Italian
• Japanese
• Korean
• Polish
• Portuguese
• Russian
• Simplified Chinese
• Spanish
• Swedish
• Traditional Chinese
• Turkish
• Ukrainian

Other convenience

• Kensington lock
• VESA mount (100 x 100 mm)

Control software SmartControl

Stand

Height adjustment 184 (Horizontal), 105 (Vertical)  mm

Tilt -5–90  degree

Folding angle 0–70 degrees

Power

ECO mode 5.6 W (typ.)

Power supply

• External
• 100–240 VAC, 50–60 Hz

Off mode 0.3 W (typ.)

On mode 7.1 W (typ.) (EnergyStar test method)

Standby mode 0.3 W (typ.)

Power LED indicator

• Operation - White
• Standby mode - White (flashing)

Energy Label ClassE

What's in the box?

• Cables
• D-Sub cable, HDMI cable, DP cable, USB-A to B cable, Audio cable, Power cable
• Monitor with stand
• Yes
• User Documentation
• Yes
• Accessory
• Stylus touch pen x 1 (black)
